Wanted: Distributors for SD11-PG2 Electro-hydraulic Directional Valves

Méthode de contrôle:Électro-hydraulique

Distributeur:4 tiroirs

Débit nominal:70 L/min (18,5 US gpm)

Pression maximale:315 bar (4 600 psi)

Orifice d'entrée:G3/4

Orifice de sortie:G3/4

Dimension du raccord:G1/2

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produit:Série SD11 Vanne directionnelle monobloc

Packagingsize:29*30*20

Grossweight:17.90 kg

Disponibilité: En stock

458 personnes consultent ce produit

Wanted: Distributors for SD11-PG2 Electro-hydraulic Directional Valves

Wanted: Distributors for SD11-PG2 Electro-hydraulic Directional Valves

Wanted: Distributors for SD11-PG2 Electro-hydraulic Directional Valves drawing image

High-performance SD11-PG2 electro-hydraulic directional control valves, offering 70 L/min flow rate and 315 bar max pressure. Ideal for material handling, construction, and agricultural machinery. Available for OEM, private label, and custom orders. Seeking global distributors, wholesalers, and trading partners.

Série SD11 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette, Électrique, Pneumatique et manuel
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs
Plage de températures ambiantes -40 °C à +60 °C (-40 °F à +140 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 70 L/min (18,5 US gpm)
Pression maximale 305 bar (4 400 psi), 315 bar (4 600 psi)
Orifice d'entrée G3/4, SAE 12
Orifice de sortie G3/4, SAE 12
Dimension du raccord G3/4, SAE 12

We are a leading manufacturer of hydraulic products, supplying globally. We offer manufacturing, OEM, private label, custom design, and wholesale services for our high-quality SD11-PG2 electro-hydraulic directional valves. These robust monoblock valves feature a 4-section design, providing precise control with a rated flow of 70 L/min (18.5 US gpm) and a maximum pressure of 315 bar (4600 psi). The operating viscosity range is 15-75 mm²/s (15-75 cSt), and they are designed for ambient temperatures ranging from -40°C to +60°C (-40°F to +140°F). With 4 spools, these valves are perfect for a wide array of applications, including material handling equipment (forklifts, telehandlers), construction and earthmoving machinery (mini-excavators, compact loaders), industrial vehicles, and agricultural machinery (tractors, harvesters, balers).

**Key Features:**
* Electro-hydraulic control
* Monoblock construction
* 4-section, 4-spool design
* High flow rate (70 L/min)
* High pressure rating (315 bar)
* Wide operating temperature range

**Business Opportunities:**
We are actively seeking distributors, wholesalers, and trading partners worldwide to expand our market reach. We offer flexible solutions including OEM, private label, and custom manufacturing options to meet your specific needs. Benefit from our factory-direct pricing and reliable supply chain. As a manufacturer, we guarantee high-quality products and efficient service. Contact us today to explore the opportunities for mutually beneficial collaboration and experience the advantages of factory direct wholesale pricing.

**Contact us now to discuss your requirements and become a valuable partner!**
