XPi-32L 32cc/rev Hydraulic Piston Pump delivers 38 MPa rated pressure for mini-excavators and loaders. Backed by a 25-year IATF 16949 certified manufacturer with 1.5M annual capacity, this left-rotation unit ensures reliable performance for construction and agricultural machinery.
| Série XPI Pompe hydraulique à pistons Paramètres | |
|---|---|
| Cylindrée | 32 cc/tr, 40 cc/tr, 45 cc/tr, 50 cc/tr, 63 cc/tr, 80 cc/tr, 25 cc/tr, 108 cm³/tr |
| Pression nominale | 38 MPa (5511 psi) |
| Pression maximale | 42 MPa (6091 psi) |
| Vitesse nominale | 1600 tr/min |
| Vitesse maximale | 1900 tr/min |
| Rotation | L : Gauche (antihoraire), R : Droite (horaire) |
| Matériau | Fonte |
| Structure | Plateau oscillant |
| Version de la bride | Trous de montage ISO-4 |
| Type d'arbre | H : Cannelures droites |
**1. High-Efficiency Hydraulic Piston Pump Specs**
- Delivers 32 cc/rev displacement with 38 MPa (5511 psi) rated pressure and 42 MPa max pressure.
- Optimized for 1600 r/min rated speed, ensuring stable flow for demanding hydraulic systems.
**2. OEM Hydraulic Pump Customization Services**
- Supported by 35+ senior engineers for tailored OEM/ODM solutions including logo laser marking.
- Flexible customization for appearance and castings to match your private label requirements.
**3. Durable 32cc Hydraulic Pump Construction**
- Manufactured in 68,000 sqm facilities using 260+ vertical machining centers for tight tolerances.
- Features left (counter-clockwise) rotation design specifically engineered for compact machinery.
**4. Certified Variable Displacement Pump Quality**
- Every unit undergoes 100% bench testing for pressure, flow, and sealing before shipment.
- Holds IATF 16949, CE, and SGS certifications with 25+ patents ensuring global compliance.
**5. Reliable Factory Direct Sales Supply Chain**
- Source directly from a professional manufacturer with 1.5 million pieces annual production capacity.
- Secure rust-proof packaging and heavy-duty wooden crates guarantee safe worldwide delivery.
