Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Méthode de contrôle:Solénoïde

Distributeur:1 tiroir

Débit nominal:45 L/min (11,8 US gpm)

Pression maximale:315 bar (4 600 psi)

Orifice d'entrée:G3/8

Orifice de sortie:G3/8

Dimension du raccord:G3/8

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série SD5 Vanne directionnelle monobloc

Taille de l'emballage:30*13*13

Poids brut:5.40 kg

Disponibilité: En stock

1131 personnes consultent ce produit

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable

Solenoid Hydraulic Valve | SD5 Model | Factory Direct & Customizable drawing image

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a durable and reliable valve designed for use in a variety of applications, including material handling, construction, agriculture, and industrial vehicles. This monoblock valve features a solenoid control method, 1 section, 40 L/min rated flow, and 305 bar maximum pressure. It's available directly from the factory and can be customized to meet your specific needs.

Série SD5 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Plage de températures ambiantes -40 °C à +60 °C (-40 °F à +140 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 40 L/min (10,5 US gpm)
Pression maximale 305 bar (4 400 psi)
Orifice d'entrée G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Orifice de sortie G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Dimension du raccord G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The SD5 Series Log Splitter Spool Valve Solenoid Hydraulic Valve is a high-performance, heavy-duty valve designed for use in demanding applications. It features a compact design, robust construction, and reliable performance. This monoblock valve is controlled by a solenoid, offering precise and responsive operation. The valve is available in a variety of configurations to meet your specific needs. It is also available with a range of options and accessories, including custom-engineered solutions. The SD5 Series is the perfect choice for a wide range of applications including material handling, construction, agriculture, and industrial vehicles. It is also suitable for use in a variety of harsh environments. Contact us today to learn more about this high-quality hydraulic valve.
