Single Spool Hydraulic Monoblock Control Valve SD14Y-OT

Méthode de contrôle:Hydraulique

Distributeur:1 tiroir

Débit nominal:120 L/min (31.7 US gpm)

Pression maximale:315 bar (4 600 psi)

Orifice d'entrée:G3/4

Orifice de sortie:G3/4

Dimension du raccord:G3/4

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série SD14 Vanne directionnelle monobloc

Taille de l'emballage:12.5*23.8*7.1

Poids brut:5.50 kg

Disponibilité: En stock

125 personnes consultent ce produit

Single Spool Hydraulic Monoblock Control Valve SD14Y-OT

Single Spool Hydraulic Monoblock Control Valve SD14Y-OT

Single Spool Hydraulic Monoblock Control Valve SD14Y-OT drawing image

The SD14Y-OT is a high-performance single spool hydraulic monoblock control valve designed for heavy-duty applications. Featuring a hydraulic control method and a rated flow of 120 L/min at 315 bar, it provides precise fluid management for construction, agricultural, and industrial machinery.

Série SD14 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Hydraulique
Distributeur 1 tiroir
Plage de températures ambiantes -40 °C à +60 °C (-40 °F à +140 °F)
Type de structure Distributeur monobloc
Section 1 section
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 120 L/min (31.7 US gpm)
Pression maximale 315 bar (4 600 psi)
Orifice d'entrée G3/4
Orifice de sortie G3/4
Dimension du raccord G3/4

Our factory is a leading manufacturer of hydraulic components, offering the SD14Y-OT Single Spool Hydraulic Monoblock Control Valve for the global market. Engineered for reliability, this SD14 series valve supports a high flow rate of 120 L/min (31.7 US gpm) and pressures up to 315 bar (4600 psi) with G3/4 porting. It is extensively used in wheel loaders, backhoe loaders, tractors, and forklifts. We provide comprehensive manufacturing services including OEM, ODM, private labeling, and custom engineering to meet specific technical requirements. As a direct factory supplier, we offer competitive wholesale pricing and are actively seeking global partners, including distributors, wholesalers, agents, and traders. Our large-scale production capacity ensures stable supply for industrial vehicle manufacturers and material handling equipment providers worldwide.
