SHFY-G25L-00 Valve Catalog | Technical Data & Ordering Information

Méthode de contrôle:Manuel

Distributeur:1 tiroir

Débit nominal:200 L/min (52 US gal/min)

Pression maximale:350 bar (5 100 psi)

Orifice d'entrée:M33×2.0

Orifice de sortie:M33×2.0

Dimension du raccord:M33×2.0

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série SHFY-G25L-00 Vanne directionnelle monobloc

Taille de l'emballage:16*32*16

Poids brut:6.50 kg

Disponibilité: En stock

1729 personnes consultent ce produit

SHFY-G25L-00 Valve Catalog | Technical Data & Ordering Information

SHFY-G25L-00 Valve Catalog | Technical Data & Ordering Information

SHFY-G25L-00 Valve Catalog | Technical Data & Ordering Information drawing image

The SHFY-G25L-00 is a manual, sectional hydraulic flow divider valve with a rated flow of 200 L/min and a maximum pressure of 315 bar. It is ideal for applications in material handling, construction, agriculture, and industrial vehicles, including telehandlers, forklifts, cranes, stackers, and more.

Série SHFY-G25L-00 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Hydraulique
Distributeur 1 tiroir
Débit nominal 200 L/min (52 US gal/min)
Pression maximale 315 bar (4 600 psi)
Orifice d'entrée M33×2.0
Orifice de sortie M33×2.0
Dimension du raccord M33×2.0
Section 1 section
Type de structure Distributeur monobloc
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Plage de viscosité de fonctionnement 12 - 400 mm²/s (12 cSt à 400 cSt)

The SHFY-G25L-00 is a high-performance hydraulic flow divider valve designed for demanding applications. Featuring manual control, a sectional valve structure, and a rated flow of 200 L/min, this valve is capable of handling a maximum pressure of 315 bar. Its operating viscosity range is 12 - 400 mm²/s, and it can withstand ambient temperatures from -40°C to +80°C. This valve is specifically designed for use in a wide range of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. Some examples of applicable models include telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, tractors and front-end loaders, and balers.
