The Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool is a high-performance valve designed for use in a wide range of hydraulic systems. With a rated flow of 160 L/min and a maximum pressure of 350 bar, this valve is capable of handling even the most demanding applications. The manual control and 4 spool design provide precise and reliable control over the flow of hydraulic fluid.
| Série SDS180 Distributeur directionnel sectionnel Paramètres | |
|---|---|
| Méthode de contrôle | Manuel, Hydraulique |
| Distributeur | 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs |
| Plage de températures ambiantes | -40 °C à +80 °C (-40 °F à +176 °F) |
| Type de structure | Distributeur à clapets |
| Section | 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections, 8 sections, 9 sections, 10 sections |
| Plage de viscosité de fonctionnement | 12 - 400 mm²/s (12 cSt à 400 cSt) |
| Débit nominal | 160 L/min (42,2 US gpm) |
| Pression maximale | 315 bar (4 600 psi), 350 bar (5 100 psi) |
| Orifice d'entrée | G3/4, G1, SAE 12 |
| Orifice de sortie | G1, SAE 16 |
| Dimension du raccord | G3/4, G1, SAE 12 |
**Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool**
**Control Method:** Manual
**Section:** 4 Section
**Structure Type:** Sectional valve
**Rated Flow:** 160 L/min (42.2 US gpm)
**Max Pressure:** 350 bar (5100 psi)
**Operating Viscosity Range:** 12 - 400 mm²/s (12 cSt to 400 cSt)
**Series:** SDS180 Series
**Application Area:** MATERIAL HANDLING, CONSTRUCTION AND EARTH MOVING, AGRICULTURE, INDUSTRIAL VEHICLES
**Applicable Model:** TELEHANDLER, FORKLIFT, ALL TERRAIN CRANE, STACKER, AERIAL PLATFORM, MOTOR GRADER, TELEHANDLER, MIDI-EXCAVATOR, MINI-EXCAVATOR, SKID STEER LOADER
The Sectional Directional Hydraulic Valve: DLS180 Micro Switch Manual 4 Spool is a versatile and reliable valve that is well-suited for a wide range of applications. Its compact design and lightweight construction make it easy to install and maintain, while its durable construction ensures long-lasting performance.
