Q45 Series 5 Spool Monoblock Hydraulic Directional Valve

Méthode de contrôle:Électroaimant push-pull

Distributeur:5 tiroirs

Débit nominal:45 L/min (11,8 US gpm)

Pression maximale:315 bar (4 600 psi)

Orifice d'entrée:G1/2

Orifice de sortie:G1/2

Dimension du raccord:G1/2

Fournisseur:BXHS

Type de produit:Vanne directionnelle monobloc

Gamme de produits:Série Q45 Vanne directionnelle monobloc

Packagingsize:30*35*17

Grossweight:19.00 kg

Disponibilité: En stock

391 Les vues recherchent ce produit

Q45 Series 5 Spool Monoblock Hydraulic Directional Valve

Q45 Series 5 Spool Monoblock Hydraulic Directional Valve

Q45 Series 5 Spool Monoblock Hydraulic Directional Valve drawing image

The Q45 Series 5 Spool Monoblock Hydraulic Directional Valve features solenoid and manual control, engineered for robust performance in mobile and industrial applications. With a 45 L/min flow and 315 bar pressure, it provides reliable hydraulic control for equipment across material handling, construction, agriculture, and industrial vehicles.

Série Q45 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Manette, Solénoïde et manuel, Électroaimant manuel et push-pull, Électroaimant push-pull
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Plage de températures ambiantes -20 °C à +80 °C (-4 °F à +176 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 45 L/min (11,8 US gpm)
Pression maximale 315 bar (4 600 psi)
Orifice d'entrée G1/2
Orifice de sortie G1/2
Dimension du raccord G1/2

Our Q45 Series 5 Spool Monoblock Hydraulic Directional Valve is engineered to deliver reliable and precise control for demanding hydraulic systems. This robust **monoblock control valve** features both **solenoid and manual control**, offering versatile operation in diverse environments. With a rated flow of 45 L/min (11.8 US gpm) and a maximum pressure of 315 bar (4600 psi), this **5 spool hydraulic valve** is designed for high-performance applications. It is a suitable **mobile hydraulic valve** solution for various industries.

This **hydraulic directional valve** is highly adaptable, serving critical functions in **material handling**, **construction equipment**, **agriculture machinery**, and **industrial vehicles**. It is compatible with a broad range of models including telehandlers, forklifts, aerial platforms, midi-excavators, mini-excavators, skid steer loaders, backhoe loaders, tractors, front-end loaders, harvesters, and dumpers. We provide solutions for **forklift hydraulic valve**, **excavator valve**, **skid steer valve**, and **backhoe loader valve** needs.

As a reputable **hydraulic valve factory** and manufacturer, we offer comprehensive services to meet global demands. We specialize in **OEM hydraulic valve** production, **ODM hydraulic valve** development, private label solutions, and **custom hydraulic valve** manufacturing, ensuring products meet specific design and performance requirements. We are a reliable source for **factory wholesale** and **factory direct valve** supply, offering competitive pricing and quality products.

We are actively seeking strategic partnerships to expand our global reach. We invite **distributors**, **wholesalers**, **agents**, and **traders** to collaborate with us. Our commitment to quality, consistent supply, and flexible manufacturing capabilities makes us an ideal partner for long-term business relationships. Explore our range of **directional control valves** and partner with a trusted **hydraulic valve supplier**.
