Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

Cylindrée:64,6 cm³/tr

Pression nominale:16 MPa (2320 psi)

Pression maximale:17 MPa (2465 psi)

Vitesse maximale:2 200 tr/min

Rotation:/: (Bidirectionnel)

Marque:BXHS

Type de produit:Pompe hydraulique à engrenages

Série de produits:Série P21 Pompe hydraulique à engrenages

Taille de l'emballage:45*25*18

Poids brut:16.00 kg

Disponibilité: En stock

158 personnes consultent ce produit

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump drawing image

This P21 Series Hydraulic Gear Pump features a 64.6 cc/rev displacement, 16 MPa rated pressure, and bidirectional rotation, ideal for forklifts and construction machinery. Backed by a Professional Manufacturer with 25+ years of experience and IATF 16949 certification, it ensures reliable OEM/ODM solutions and Factory Direct Sales quality.

Série P21 Pompe hydraulique à engrenages Paramètres
Cylindrée 64,6 cm³/tr
Pression nominale 16 MPa (2320 psi)
Pression maximale 17 MPa (2465 psi)
Vitesse nominale 600 tr/min
Vitesse maximale 2 400 tr/min
Rotation /: (Bidirectionnel)
Matériau Fonte
Structure Pompe à engrenages externes
Version de la bride A - Bride ovale, B - Bride carrée, Trous de montage ISO-4, Trous de montage UNI-3, Bride SAE
Type d'arbre X : Cannelures hélicoïdales

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers precise 64.6 cc/rev displacement with a rated pressure of 16 MPa (2320 psi) and max pressure of 17 MPa, ensuring stable power output for heavy-duty applications.
- Operates efficiently at a rated speed of 2000 r/min (max 2200 r/min) with bidirectional rotation capability, offering versatile installation options for diverse hydraulic systems.

**2. Versatile P21 Series Gear Pump Applications**
- Specifically engineered for material handling and earth-moving equipment, including forklifts, telehandlers, skid steer loaders, and backhoe loaders.
- Compatible with agricultural and industrial vehicles like tractors, sprayers, and waste compactors, providing a direct replacement for international mainstream brands with perfect fitment.

**3. Reliable Bidirectional Gear Pump Quality Control**
- Manufactured in our 68,000 sqm facility with 260+ vertical machining centers, every unit undergoes 100% bench testing for pressure, flow, and sealing integrity before shipment.
- Certified under IATF 16949 and CE standards, with SGS professional detection and 25+ autonomous patents, guaranteeing zero-defect performance and long service life.

**4. Customizable OEM/ODM Available Solutions**
- Supported by 35+ senior engineers with 10+ years of experience, we offer full customization including appearance, casting modifications, and exclusive logo laser marking for your Private Label needs.
- As a China Wholesale hub, we provide flexible OEM/ODM services to meet specific technical requirements, helping distributors build their own brand identity with Factory Direct support.

**5. Secure Factory Direct Sales & Logistics**
- Enjoy Wholesale Direct Sales advantages from a source factory with an annual capacity of 1,500,000 units, ensuring timely delivery and competitive pricing for bulk orders.
- Products are protected with anti-rust treatment and heavy-duty wooden crates/pallets, ensuring safe global transit and making us the preferred partner for Exported Worldwide projects.
