P40-U34 Directional Valve | High-Pressure & Long Service Life

Méthode de contrôle:Manuel

Distributeur:1 tiroir

Débit nominal:40 L/min (10,5 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:SAE 8

Orifice de sortie:SAE 8

Dimension du raccord:SAE 8

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série P40 Vanne directionnelle monobloc

Taille de l'emballage:23*16*11

Poids brut:3.00 kg

Disponibilité: En stock

1083 personnes consultent ce produit

P40-U34 Directional Valve | High-Pressure & Long Service Life

P40-U34 Directional Valve | High-Pressure & Long Service Life

P40-U34 Directional Valve | High-Pressure & Long Service Life drawing image

This P40 Series hydraulic solenoid valve is a high-performance directional control valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. It features a 220 Volt operation, high pressure rating, long service life, and a compact monoblock structure.

Série P40 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette, Solénoïde et manette, Manuel et manette, Solénoïde et câble
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 40 L/min (10,5 US gpm)
Pression maximale 250 bar (3 600 psi)
Orifice d'entrée G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Orifice de sortie G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Dimension du raccord G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-U34 directional valve is a robust and reliable hydraulic solenoid valve built for heavy-duty applications. This 220 Volt valve provides precise control of hydraulic fluid flow with a maximum pressure rating of 250 bar (3600 psi). The valve boasts a long service life, thanks to its durable construction and high-quality materials. Designed as a monoblock valve, the P40-U34 offers a compact and efficient solution for a wide range of applications. It is perfect for use in telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The valve's operating viscosity range of 15-75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure reliable operation in a variety of harsh environments.
