Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Méthode de contrôle:Manuel

Distributeur:2 tiroirs

Débit nominal:80 L/min (21,2 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:G1/2

Orifice de sortie:G3/4

Dimension du raccord:G1/2

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série P80 Vanne directionnelle monobloc

Taille de l'emballage:26*18*11

Poids brut:8.00 kg

Disponibilité: En stock

1151 personnes consultent ce produit

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design drawing image

The P80-G12-G38-QW steering control valve is a compact and robust monoblock directional valve designed for demanding applications in material handling, construction, and agriculture. It features a manual control method, 2 sections, and a rated flow of 80 L/min. The valve is suitable for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, and excavators.

Série P80 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette, Manuel et manette
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 80 L/min (21,2 US gpm)
Pression maximale 315 bar (4 600 psi)
Orifice d'entrée G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Orifice de sortie G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Dimension du raccord G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This P80 Series steering control valve is a high-performance, compact, and robust monoblock directional valve designed for demanding applications. With its manual control method and 2 sections, it provides precise and reliable control of hydraulic systems. The valve features a rated flow of 80 L/min and a maximum pressure of 250 bar. It is suitable for a wide range of applications, including material handling, construction, and agriculture. The valve's compact and robust design makes it ideal for use in tight spaces and demanding environments. Its high flow rate and pressure rating ensure reliable performance under heavy loads. The valve is compatible with various machines and equipment, such as telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, backhoe loaders, and skip loaders.
