Manual Monoblock Directional Valve P80-G34-2OT

Méthode de contrôle:Manuel

Distributeur:2 tiroirs

Débit nominal:80 L/min (21,2 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:G3/4

Orifice de sortie:G3/4

Dimension du raccord:G3/4

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série P80 Vanne directionnelle monobloc

Taille de l'emballage:26*18*11

Poids brut:8.00 kg

Disponibilité: En stock

1075 personnes consultent ce produit

Manual Monoblock Directional Valve P80-G34-2OT

Manual Monoblock Directional Valve P80-G34-2OT

Manual Monoblock Directional Valve P80-G34-2OT drawing image

The P80-G34-2OT is a high-performance, manual, monoblock directional valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. It features pressure-independent balancing control, a rated flow of 80 L/min, and a maximum pressure of 250 bar.

Série P80 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette, Manuel et manette
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Type de structure Distributeur monobloc
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 80 L/min (21,2 US gpm)
Pression maximale 315 bar (4 600 psi)
Orifice d'entrée G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Orifice de sortie G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Dimension du raccord G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G34-2OT is a 2-section, manual monoblock directional valve with a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). It is designed for use in hydraulic systems with operating viscosities ranging from 15 to 75 mm²/s (15 cSt to 75 cSt). The valve features pressure-independent balancing control, ensuring smooth and reliable operation in various applications. Its compact design and robust construction make it suitable for demanding environments. The P80-G34-2OT is commonly used in a wide range of equipment including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its versatility and reliability make it a preferred choice for manufacturers and users in various industries.
