Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Méthode de contrôle:Manuel

Distributeur:1 tiroir

Débit nominal:80 L/min (21,2 US gpm)

Pression maximale:Pression maximale

Orifice d'entrée:G1/2

Orifice de sortie:G3/4

Dimension du raccord:G3/4

Marque:BXHS

Type de produit:Valve de Fendeuse à Bûches

Série de produits:Série P81 Valve de Fendeuse à Bûches

Taille de l'emballage:27*16*12

Poids brut:4.80 kg

Disponibilité: En stock

2167 personnes consultent ce produit

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable drawing image

The P81 hydraulic valve is a high-performance, heavy-duty valve designed for use in tractor-powered log splitters. It features a manual control method, 1 section monoblock construction, 80 L/min flow rate, and 250 bar maximum pressure. This durable valve is perfect for industrial applications and offers customizable options to meet your specific needs.

Série P81 Valve de Fendeuse à Bûches Paramètres
Méthode de contrôle Manuel
Distributeur 1 tiroir
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Type de structure Distributeur monobloc
Section 1 section
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 80 L/min (21,2 US gpm), 95 L/min (25,1 US gpm)
Pression maximale Pression maximale
Orifice d'entrée G1/2
Orifice de sortie G1/2
Dimension du raccord G3/4

The P81 model is a robust tractor joy stick log splitter hydraulic valve, ideal for industrial vehicles. This monoblock valve boasts a 1 section design and offers a rated flow of 80 L/min (21.2 US gpm) with a maximum pressure of 250 bar (3600 psi). It operates within a wide viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve features a single spool with a kick-out setting pressure of 70~140bar (1015-2030psi). We offer this valve for manufacturing, OEM, private label, and custom orders, allowing you to tailor it to your specific requirements. We are also actively seeking distributors, wholesalers, agents, and traders worldwide. Contact us today to discuss your needs and explore the possibilities of this high-quality, customizable hydraulic valve.
