Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Méthode de contrôle:Manuel

Distributeur:1 tiroir

Débit nominal:120 L/min (31.7 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:G1

Orifice de sortie:G1

Dimension du raccord:G1

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série P120 Vanne directionnelle monobloc

Taille de l'emballage:19*35*16

Poids brut:13.60 kg

Disponibilité: En stock

979 personnes consultent ce produit

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve

Hydraulic Product Manufacturer: P120-G1 Monoblock Valve drawing image

The P120-G1 Monoblock Valve is a high-performance, adjustable hydraulic flow divider valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual control valve features a compact, robust design with a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi).

Série P120 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Manuel, Câble, Manette, Manuel et manette
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs
Débit nominal 120 L/min (31.7 US gpm)
Pression maximale 250 bar (3 600 psi)
Orifice d'entrée G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Orifice de sortie G1, SAE 16, 1 NPT, M36×2
Dimension du raccord G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Section 1 section, 2 sections, 3 sections, 4 sections
Type de structure Distributeur monobloc
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)

The P120-G1 Monoblock Valve is a reliable and efficient solution for controlling hydraulic flow in demanding applications. Its robust monoblock construction ensures durability and long service life. This adjustable flow divider valve allows for precise control of hydraulic fluid flow, enabling optimized performance in various equipment such as telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. The valve operates at a flow rate of 120 L/min (31.7 US gpm) and a maximum pressure of 250 bar (3600 psi), making it suitable for high-demand applications. The manual control method provides simple and direct operation. The P120-G1 Monoblock Valve is a versatile and reliable solution for a wide range of applications in the construction, agriculture, and industrial vehicle sectors.
