Hydraulic Control Valve | P80F-G34-OT Series Manufacturer

Méthode de contrôle:Manuel

Distributeur:5 tiroirs

Débit nominal:80 L/min (21,2 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:G3/4

Orifice de sortie:G3/4

Dimension du raccord:G3/4

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série P80F Vanne directionnelle monobloc

Taille de l'emballage:26*30*11

Poids brut:16.00 kg

Disponibilité: En stock

1226 personnes consultent ce produit

Hydraulic Control Valve | P80F-G34-OT Series Manufacturer

Hydraulic Control Valve | P80F-G34-OT Series Manufacturer

Hydraulic Control Valve | P80F-G34-OT Series Manufacturer drawing image

The P80F-G34-OT Series Electro Hydraulic Proportional Valve is a high-performance, 5-section, monoblock valve designed for heavy-duty applications in material handling, construction, and industrial vehicles. This valve features a rated flow of 80 L/min (21.2 US gpm), a maximum pressure of 250 bar (3600 psi), and a wide operating viscosity range. With its manual control and robust design, it provides reliable and precise control for a variety of applications.

Série P80F Vanne directionnelle monobloc Paramètres
Distributeur 1 tiroir, 2 tiroirs, 3 tiroirs, 4 tiroirs, 5 tiroirs, 6 tiroirs, 7 tiroirs
Méthode de contrôle Manuel, Pneumatique, Électro-pneumatique, Électro-hydraulique, Solénoïde, Hydraulique, Hydraulique et manuel, Câble, Manette
Dimension du raccord G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Section 1 section, 2 sections, 3 sections, 4 sections, 5 sections, 6 sections, 7 sections
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Orifice de sortie G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT
Pression maximale 315 bar (4 600 psi)
Débit nominal 80 L/min (21,2 US gpm)
Type de structure Distributeur monobloc
Orifice d'entrée G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

The P80F-G34-OT Series Electro Hydraulic Proportional Valve is a high-performance, 5-section, monoblock valve designed for heavy-duty applications in material handling, construction, and industrial vehicles. This valve features a rated flow of 80 L/min (21.2 US gpm), a maximum pressure of 250 bar (3600 psi), and a wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its manual control allows for precise operation, while its robust construction ensures durability and reliability in demanding environments. The P80F Series is suitable for a wide range of applications, including telehandlers, forklifts, all terrain cranes, stackers, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, backhoe loaders, harvesters, and bale wrappers. With its customizable features and high performance, this valve is an ideal choice for manufacturers and users seeking reliable and efficient hydraulic control solutions.
