HSDM80 Series 2 Spool Hydraulic Monoblock Directional Control Valve

Méthode de contrôle:Câble

Distributeur:2 tiroirs

Débit nominal:80 L/min (21,2 US gpm)

Pression maximale:250 bar (3 600 psi)

Orifice d'entrée:G3/4

Orifice de sortie:G3/4

Dimension du raccord:G1/2

Marque:BXHS

Type de produit:Vanne directionnelle monobloc

Série de produits:Série HSDM80 Vanne directionnelle monobloc

Taille de l'emballage:34*24*15.5

Poids brut:14.00 kg

Disponibilité: En stock

96 personnes consultent ce produit

HSDM80 Series 2 Spool Hydraulic Monoblock Directional Control Valve

HSDM80 Series 2 Spool Hydraulic Monoblock Directional Control Valve

HSDM80 Series 2 Spool Hydraulic Monoblock Directional Control Valve drawing image

The HSDM80 Series is a high-performance 2-spool monoblock hydraulic directional control valve featuring cable control operation. With a rated flow of 80 L/min and a maximum pressure rating of 250 bar, it provides reliable fluid power management for various mobile and industrial applications.

Série HSDM80 Vanne directionnelle monobloc Paramètres
Méthode de contrôle Câble
Distributeur 2 tiroirs
Plage de températures ambiantes -40 °C à +80 °C (-40 °F à +176 °F)
Type de structure Distributeur monobloc
Section 2 sections
Plage de viscosité de fonctionnement 15 - 75 mm²/s (15 cSt à 75 cSt)
Débit nominal 80 L/min (21,2 US gpm)
Pression maximale 250 bar (3 600 psi)
Orifice d'entrée G3/4
Orifice de sortie G3/4
Dimension du raccord G1/2

As a leading manufacturer of hydraulic components, we proudly offer the HSDM80 Series 2 Spool Hydraulic Monoblock Directional Control Valve. This robust cable-controlled valve is engineered for precision and durability, delivering a flow rate of 80 L/min (21.2 US gpm) and sustaining pressures up to 250 bar (3600 psi). It features G3/4 inlet/outlet ports and G1/2 work ports to ensure versatile connectivity. We specialize in global supply, providing comprehensive OEM, ODM, and custom manufacturing services to meet specific technical requirements. Our factory supports large-scale wholesale and private labeling for international brands. We are actively seeking long-term partnerships with professional distributors, wholesalers, agents, and traders worldwide. By choosing our factory supply, you gain access to competitive pricing, reliable technical support, and the capacity for high-volume orders. Ideal for agricultural machinery, construction equipment, and specialized mobile applications, the HSDM80-2 valve ensures efficient performance under demanding conditions.
