Our High-Performance Hydraulic Gear Pump is designed for various applications such as material handling, construction, agriculture, and industrial vehicles. It features a displacement of 32 cc/rev, 50 cc/rev, or 63 cc/rev, a rated pressure of 20 MPa (2900 psi), and a rated speed of 2000 r/min with a maximum speed of 2200 r/min. The pump has a cast iron construction and is available with different flange versions, shaft types, and rotation directions.
| Série CBHS-F5 Pompe hydraulique à engrenages Paramètres | |
|---|---|
| Cylindrée | 32 cc/tr, 50 cc/tr, 63 cc/tr, 20 cc/tr |
| Pression nominale | 20 MPa (2900 psi) |
| Pression maximale | 25 MPa (3625 psi) |
| Vitesse nominale | 2 000 tr/min |
| Vitesse maximale | 2 500 tr/min |
| Rotation | L : Gauche (antihoraire), R : Droite (horaire) |
| Matériau | Fonte |
| Structure | Pompe à engrenages externes |
| Version de la bride | B - Bride carrée |
| Type d'arbre | H : Cannelures droites, X : Cannelures hélicoïdales, P : Clé simple |
**High-Performance Hydraulic Gear Pump: Specifications**
**Displacement:**
- 32 cc/rev
- 50 cc/rev
- 63 cc/rev
**Rated Pressure:** 20 MPa (2900 psi)
**Rated Speed:** 2000 r/min
**Max Speed:** 2200 r/min
**Rotation:**
- L: Left (counter-clockwise)
- R: Right (clockwise)
**Structure:** Internal Gear Pump
**Material:** Cast Iron
**Flange Version:** B-Square Flange
**Shaft Type:**
- P: Plain Key
- H: Rectangle Spline
- X: Involute Spline
**Series:** CBHS-F5 Series
**Application Area:**
- MATERIAL HANDLING
- CONSTRUCTION AND EARTH MOVING
- AGRICULTURE
- INDUSTRIAL VEHICLES
**Applicable Model:**
- TELEHANDLER
- FORKLIFT
- ALL TERRAIN CRANE
- STACKER
- AERIAL PLATFORM
- MOTOR GRADER
- MIDI-EXCAVATOR
- MINI-EXCAVATOR
- SKID STEER LOADER
- COMPACT WHEEL LOADER
