Production et livraison
Délai de production de 15 à 30 jours



High-quality BZZ5-E100B hydraulic steering unit (100 ml/r displacement, 16 MPa max pressure) for material handling, construction, agriculture, and industrial vehicles. Cast iron construction. OEM, ODM, and wholesale opportunities available.
| Série BZZ5 Unité de direction Paramètres | |
|---|---|
| Cylindrée | 50 ml/tr, 63 ml/tr, 100 ml/tr, 80 ml/tr, 125 ml/tr, 160 ml/tr, 200 ml/tr, 250 ml/tr, 280 ml/tr, 315 ml/tr, 400 ml/tr, 500 ml/tr, 630 ml/tr, 800 ml/tr, 1000 ml/tr |
| Bloc de vannes | Personnalisable |
| Matériau | Fonte |
| Débit nominal | 5 L/min, 6 L/min, 4 L/min, 7,5 L/min, 9,5 L/min, 12 L/min, 15 L/min, 19 L/min, 21 L/min, 24 L/min, 30 L/min, 38 L/min, 48 L/min, 60 L/min, 75 L/min |
| Contre-pression maximale continue | 1,6 Mpa |
| Pression d'entrée maximale | 16 Mpa |
We are a hydraulic product manufacturer offering global distribution of the BZZ5-E100B hydraulic steering unit. This robust unit features a 100 ml/r displacement, a maximum input pressure of 16 MPa, and a maximum continuous back pressure of 1.6 MPa. Its rated flow is 7.5 L/min. The unit is constructed from durable cast iron for long-lasting performance. The valve block is customizable to meet specific application needs. It's ideal for a wide range of applications, including forklifts, telehandlers, skid steer loaders, compact wheel loaders, tractors and front-end loaders, mini-excavators, backhoe loaders, harvesters, and balers.
**Collaborate with Us:** We are seeking distributors, wholesalers, dealers, and trading companies worldwide to partner with us. We offer a full range of services, including manufacturing, OEM (Original Equipment Manufacturing), ODM (Original Design Manufacturing), private labeling, and wholesale options. As a factory-direct supplier, we ensure competitive pricing and high-quality products. Contact us today to discuss partnership opportunities and explore the potential of our BZZ5-E100B hydraulic steering unit. We provide factory wholesale prices and offer flexible customization options to meet your specific requirements. Let's work together to grow your business!
