The CBHS-F550 Gear Pump is a high-performance hydraulic pump designed for demanding applications in various industries. With a displacement of 50 cc/rev and a rated pressure of 20 MPa, it delivers exceptional power and efficiency.
| Série CBHS-F5 Pompe hydraulique à engrenages Paramètres | |
|---|---|
| Cylindrée | 32 cc/tr, 50 cc/tr, 63 cc/tr, 20 cc/tr |
| Pression nominale | 20 MPa (2900 psi) |
| Pression maximale | 25 MPa (3625 psi) |
| Vitesse nominale | 2 000 tr/min |
| Vitesse maximale | 2 500 tr/min |
| Rotation | L : Gauche (antihoraire), R : Droite (horaire) |
| Matériau | Fonte |
| Structure | Pompe à engrenages externes |
| Version de la bride | B - Bride carrée |
| Type d'arbre | H : Cannelures droites, X : Cannelures hélicoïdales, P : Clé simple |
**CBHS-F550 Gear Pump: Technical Specifications**
- Displacement: 50 cc/rev
- Rated Pressure: 20 MPa
- Rated Speed: 2000 r/min
- Max Speed: 2200 r/min
- Rotation: Left (counter-clockwise) or Right (clockwise)
- Structure: Internal Gear Pump
- Material: Cast Iron
- Flange Version: B-Square Flange
- Shaft Type: Plain Key, Rectangle Spline, or Involute Spline
**Applications:**
- Material Handling Equipment
- Construction and Earth Moving Machinery
- Agricultural Equipment
- Industrial Vehicles
**Applicable Models:**
- Telehandlers
- Forklifts
- All Terrain Cranes
- Stackers
- Aerial Platforms
- Motor Graders
- Midi-Excavators
- Mini-Excavators
- Skid Steer Loaders
- Compact Wheel Loaders
